43 ROM-5420 B1/B2 User Manual
Chapter 3 Software Functionality
3.8.5.2 Single Display Settings
HDMI out, please set in u-boot as below:
setenv bootargs_mmc 'setenv bootargs ${bootargs} root=/dev/mmc-
blk1p1 rootwait rw video=mxcfb0:dev=hdmi,1920x1080M@60,if=RGB24'
VGA out, please set in u-boot as below:
setenv bootargs_mmc 'setenv bootargs ${bootargs} root=/dev/mmc-
blk1p1 rootwait rw video=mxcfb0:dev=lcd,1920x1080M@60,if=RGB24'
LVDS 1(Single) out, please set in u-boot as below:
setenv bootargs_mmc 'setenv bootargs ${bootargs} root=/dev/mmc-
blk1p1 rootwait rw video=mxcfb0:dev=ldb,1920x1080M@60,if=RGB24
ldb=sin0'
LVDS 2(Split) out, please set in u-boot as below:
setenv bootargs_mmc 'setenv bootargs ${bootargs} root=/dev/mmc-
blk1p1 rootwait rw video=mxcfb0:dev=ldb,1920x1080M@60,if=RGB24
ldb=sin1'
3.8.5.3 Multi-Display Settings
When you want to display dual LVDS, VGA, and HDMI output, please set the param-
eters in U-boot as follows. These are the default settings in u-boot.
setenv bootargs_mmc 'setenv bootargs ${bootargs} root=/dev/mmcblk1p1
rootwait
setenv bootargs_base 'setenv bootargs console=ttymxc0,115200
enable_wait_mode=off video_mode=extension'
For the display interface clock, there are several options (Independent for each port)
listed below:
1. Derived from the IPU internal clock (Master Mode)\
2. Provided by an external source (Slave Mode)
3. Transfer rate supported
When a single port is active, the pixel clock rate is up to 264 MHz.
When both LVDS ports are active, you have to follow the below condition:
1. Each pixel clock rate may be up to 220 MHz.**
2. The sum of pixel clock rates is up to 240 MHz.
3.8.6 Network Setup
Default: IP is obtained from DHCP.
Manual: Set IP with the following command:
#ifconfig eth0 192.168.0.1 up
Note! Specified pixel clock frequencies are applicable for internal clocks, but
may be limited by I/O buffer speed capability. Final numbers are sub-
jected to AC characterization.
