37 ROM-5420 B1/B2 User Manual
Chapter 3 Software Functionality
3.5.2 Change the ROM-5420 Boot Logo
By default, ROM-5420 shows a boot logo when booting up. You can replace the logo
to whatever your want by following the steps below:
1. First, you have to download “netpbm” corresponding to your OS version from
the Internet.
2. Install “netpbm” by typing $sudo apt-get install netpbm.
3. Prepare your boot logo. For example: bootlogo.png (Under folder Desktop/boot-
logo)
4. Open "Terminal" on Ubuntu 10.04 LTS..
5. $sudo su (Change to “root” authority)
6. Input user password.
7. #cd Desktop/bootlogo (Go into the folder that bootlogo.png located)
8. #pngtopnm bootlogo.png | ppmquant 224 | pnmtoplainpnm > logo_li-
nux_clut224.ppm
9. #cp logo_linux_clut224.ppm \
../5420LBVxxxx/source/linux-3.0.35/drivers/video/logo/
10. Then you can refer Chapter 3.3.1 to rebuild the kernel with your own boot logo.
3.6 Create a Linux System Boot Media
ROM-5420 supports boot from an SD card, SATA device, or onboard flash memory.
This section will guide you how to build an image for ROM-5420 Linux system boot
media.
3.6.1 Create a Linux System SD Card
3.6.1.1 From the Source Code Package
When you receive the ROM-5420 Linux source code package, you can refer to the
following steps to create a Linux system SD card which can be booted from.
1. Open "Terminal" on Ubuntu 10.04 LTS.
2. $sudo su (Change to “root” authority)
3. Input your password.
4. Insert one SD card to your development computer.
5. Check the SD card location, like: /dev/sdf
6. Change the directory to BSP scripts folder.
7. #./mksd-linux.sh /dev/sdf
8. Type “y” (Start to copy the files and wait until it shows [Done]).
Then insert the Linux system SD card to the ROM-5420 SD card slot (SD1). It will
boot to the Linux environment.
3.6.2 Boot from Onboard Flash
If you already have a Linux system SD card, you can refer to the following steps to
copy the content to the onboard flash and then boot from onboard flash. Advantech
also provides you a script called “mkinand-linux.sh” to speed up the process of
installing the system image to the onboard flash.
Note! This picture should be in PNG format and less than 224 colors. It is sug-
gested to have the image resolution equal to your LCD panel size.
