ROM-5420 B1/B2 User Manual 30
3.2 Package Content
We offer two different Linux packages for ROM-5420. One is a pre-built system
image for system recovery and the other is a source code package (BSP).
3.2.1 Source Code Package
The ROM-5420 source code package (BSP) contains a cross compiler, Linux source
code, Uboot source code, a root file system and some scripts used in OS develop-
ment. Some of the above components were developed by Advantech and the others
were developed by the open source community. The ROM-5420 source code pack-
age is composed of six main folders: “cross_compiler”, “document”, “image”, “pack-
age”, “scripts”, and “source”.
Description of the 5420LBVxxxx package contents:
3.2.1.1 cross_compiler
You can use the cross compiler toolchain to compile the image and related applica-
tions. (gcc version is 4.6.2 20110630)
The toolchain directory structure is as follows:
|-- bin // toolchain with prefix, such as arm-none-linux-gnueabi-gcc etc.
|-- lib // library files used for toolchain itself, not for application
|-- arm-fsl-linux-gnueabi
|-- bin // toolchain without prefix, such as gcc.
|-- debug-root // all debug tools
|-- multi-libs // all libraries and headers.
|-- armv5 // library for armv5 (i.mx 2xx). only support soft float point
|-- armv6 // library for armv6 (i.mx 3xx), soft fpu version
|-- armv7-a // library for armv7-a (i.mx5xx and i.mx6xx), hardware fpu version
|-- lib //default library. It can be used for armv4t and above.
|-- usr
|-- include //header files for the application development
|-- lib //three-part library and static built library Freescale
Note! The ROM-5420 source code package (BSP) is intellectual property of
Advantech. If you need to access this package, please contact your
Advantech support representative.
“cross_compiler” → This folder contains source code for the cross compiler.
“document” → This folder contains a user guide.
“image” → This folder contains the image, and the script for making Linux
system media automatically.
“image/rootfs” → This folder contains the Linux root file system.
“package” → This folder contains the source code provided by NXP without
any modifications.
“scripts” → This folder contains scripts to configure the system and com-
pile images automatically.
“source” → This folder contains source code owned by Advantech.
