3 ROM-5420 B1/B2 User Manual
Chapter 1 Product Overview
1.2 Product Features
*4 x I2C have been reserved for power management, camera, LCD display ID, and
HDMI support. You can use them for other purposes if you do not need those fea-
tures.
Compatible Module SMARC v1.1
Processor System CPU
NXP ARM Cortex-A9 i.MX6 800MHz/
1.0GHz
Memory
Technology DDR3 1066 MHz
Capacity On-board DDR3 512MB/1GB/2GB
Flash
16 GB eMMC for OS and 4MB NOR Flash
for Advantech boot loader
Graphics
Graphics Engine
3 GPUs. OpenGL ES 2.0 for 3D, BitBit for
2D and OpenVG 1.1
H/W Video Codecs
Decoders: MPEG-4 ASP, H.264 HP, H.263,
MPEG-2 MP, MJPEG BP
Encoders: MPEG-4 SP, H.264 BP, H.263,
MJPEG BP
HDMI 1920 x 1080 at 60Hz
LVDS 1 x 24-bit TTL, 1920 x 1200 @ 60Hz
Parallel RGB 1 x 24-bit TTL,1920 x 1200 @ 60Hz
Ethernet
Chipset NXP i.MX6 integrated RGMII
Speed 1 x 10/100/1000 Mbps, Max. 400Mbps
Watchdog Timer
256-level interval timer, from 0 ~ 128 sec,
multi-option S/W watchdog timer
I/O
PCIe 1 x PCIe x1
SATA 1 x SATA II
USB 1 x USB 2.0, 1 x USB 2.0 OTG
Audio I2S
SDIO 4-bit SDIO
Serial Ports 4 x UART (2x2 wire, 2x4 wire w/ 3.3 V)
SPI 4
CAN 2 x CAN bus 2.0B
GPIO 12
I2C *5 x I2C
OS Linux & Android
Power Supply Voltage +3 ~ 5.25 V
Environment
Operation 0 ~ 60°C / -40 ~ 85°C
Operating Humidity 0 ~ 90% relative humidity, non-condensing
Physical
Characteristics
Dimensions (w x d) 82 x 50 mm
Camera Input Dimensions (w x d) 1 MIPI v1.0, 4 x lanes
