1.1 Introduction
Advantech ROM-3620 RTX2.1 Computer-on-Module is powered by NXP i.MX 8X
SoC which includes two to four Arm Cortex-A35 cores for mid-range automotive and
industrial market segments, one Cortex-M4F core for real-time processing, and one
Tensilica Hi-Fi 4 DSP for efficient audio and voice codec execution. It also escalates
its graphic performance by Vivante GC7000 Lite, 4K H.265 capable decoder, and
dual 1080P60 display controller.
ROM-3620 RTX2.1 module offers an Advantech ROM-DB3900 evaluation carrier
board for easy integration and hardware design reference, and also provides a Linux
BSP utility and reference codes for application development and device integration.
1.2 Product Features
1.2.1 Specification
Form Factor RTX v2.1
Processor
System
CPU
NXP i.MX 8X DualXPlus/QuadXPlus; 2/4 x Arm Cortex-
A35 1.2GHz; Cortex M4F
Memory
Technology LPDDR4
Capacity On-board 2GB/4GB
Flash 16 GB eMMC NAND Flash and 8MB QSPI NOR FLASH
Graphics
LVDS/MIPI DSI
2 x 24-bit single channel LVDS 1080p or 2 x 4-LANE
MIPI DSI
Graphics Engine Vivante GC7000 Lite
H/W Video Codec
Decoder: H.265/H.264
Encoder: H. 264
Ethernet
Chipset 2 x NXP i.MX8X integrated RGMII (with AR8035)
Speed 2 x 10/100/1000 Mbps
PMIC PMIC NXP PF8100
RTC RTC Yes
WatchDog
Timer
256-level timer interval, from 0 ~ 128 sec
I/O
PCIe 1 x PCIe 3.0
USB
1 USB 3.0, 1 USB 2.0
1 USB 2.0 OTG
Audio
I
2
S
SPDIF -
SDIO 1
Serial Port 3 UART (1 x 4 wire/ 2 x 2 wire)
SPI 2
CAN 2 CAN/CAN-FD
GPIO 10
I
2
C
5
Camera Input 1 x 4-lane MIPI CSI
System Bus -
Touch -
Keypad -
Power
Power Supply Voltage 5 ~ 24 V
Power Consumption 4.497W (Max)
