3 ROM-3420 User Manual
Chapter 1 Product Overview
1.2 Product Features
Compatible Module RTX 2.0
Processor System CPU Freescale i.MX6 Dual Core 1.0 GHz
Memory
Technology DDR3 1066 MHz
Capacity On-board DDR3 1 GB
Flash
4 GB eMMC for O.S. and 4 MB NOR
Flash for Advantech boot loader
Graphic
Graphics Engine
2 GPUs. OpenGL ES 2.0 for 3D, BitBlt
for 2D and OpenVG 1.1
H/W Video Codec
Decoder: MPEG-4 ASP, H.264 HP,
H.263, MPEG-2 MP, MJPEG BP
Encoder: MPEG-4 SP, H.264 BP,
H.263, MJPEG BP
HDMI 1 HDMI
LVDS 1 single 24-bit LVDS
TTL LCD 24-bit TTL LCD
Ethernet
Chipset
Freescale i.MX6 Dual integrated
RGMII
Speed 1 10/100/1000 Mbps, Max. 400Mbps
Watch Dog Timer
256 Level timer interval, from 0 ~ 128
sec, multi-option S/W watchdog timer
I/O
PCIe 1 PCIe
SATA 1 SATA II
USB 1 USB 2.0, 1 USB2.0 OTG
Audio HD Audio with I2S
Serial Port 3 UART (3 x 4 wires w/ 3.3 V)
SPI 1 SPI
CAN 2 CAN bus 2.0B
GPIO 10 GPIO
I2C 4 I2C
System bus
Address: 26-bits, Data: 16-bits, 2 chip
select pins
O.S Linux 3.0.35
Power Supply Voltage 5 ~ 24 V
Environment
Operation 0 ~ 60° C
Operating Humidity
0% ~ 90% relative humidity, non-con-
densing
Physical
Characteristics
Dimensions (WxD) 68 x 68 mm
