ROM-3310 User Manual 2
1.1 Introduction
ROM-3310 adopts TI Cortex A8 AM3352 1Ghz architecture as its SOC solution. The
main features of this platform are followed by RTX 2.0 standard, with a heat-sink-
less, compact, reliable & great power management. Therefore, ROM-3310 platform
is suitable for following applications:
Industrial data collector
And the main features of TI Cortex A8 processors are shown as following:
ARM Cortex™-A8 high performance processor, single core 1GHz
Support Parallel RGB 24bit TTL
TI AM3352 Cortex A8 Technology support low power consumption
Capabilities of I/O expansion: UART(5), 24bit TTL,USB Host, USB OTG, Gigabit
Ethernet, SD,GPIO(10), I2C(1), SPI(1), I2S, CAN with 3.3V level (2)
Supports Linux Kernel 3.2.0
Support working temperature 0 ~ 60°C & -40 ~ 85°C
1.2 Product Features
Form factor RTX 2.0
Processor System CPU TI Cortex A8 AM3352 1Ghz
Memory
Technology DDR3 800 MHz
Capacity On-board DDR3 512MB
Flash
4GB eMMC for O.S. and 4MB NOR Flash for ADV
Loader
Graphic 24bit TTL Parallel RGB VGA
Ethernet
Transceiver RTL8211
Speed 1 x 10/100/1000 Mbps
Watch Dog Timer HW WDT TI MSP430G2202 (time out 1~6553s, default 60s)
I/O
SDIO 4-bit STD SD
Serial Port 5 x UART (1 x RS485, 4 x RS232)
SPI 1 x SPI
CAN 2 x CAN 2.0B
GPIO 10 x GPIO
I2C 1 x I2C
I2S 1 x I2S
USB 1 x USB 2.0 host & 1 x USB 2.0 OTG
O.S Linux Kernel V 3.2.0
Dimensions W x L x T 68 x 68 mm x 2mm
Power DC-In 5~24V
Environment
Operational
Temperature
0 ~ 60°C/ -40 ~ 85° C
Operating
Humidity
0% ~ 90% relative humidity, non-condensing
Certifications Level CE / FCC / Class B
