4 PPC-MB-610 Startup Manual
COM12: COM 2 Connector
Pin
Denition
(RS-232)
Denition
(RS-422)
Denition
(RS-485)
1 DCD TX- TX RX-
2 RXD TX+ TX RX+
3 TXD RX+
4 DTR RX-
5 GND
6 DSR
7 RTS
8 CTS
9 RI
CN6: COM 3/4/5 and GPIO Connector
1 COM3_DCD# 2 COM3_DSR#
3 COM3_RXD 4 COM3_RTS#
5 COM3_TXD 6 COM3_CTS#
7 COM3_DTR# 8 COM3_RI#
9 GND 10 GND
11 COM4_DCD# 12 COM4_DSR#
13 COM4_RXD 14 COM4_RTS#
15 COM4_TXD 16 COM4_CTS#
17 COM4_DTR# 18 COM4_RI#
19 GND 20 GND
21 COM5_DCD# 22 COM5_DSR#
23 COM5_RXD 24 COM5_RTS#
25 COM5_TXD 26 COM5_CTS#
27 COM5_DTR# 28 COM5_RI#
29 GND 30 GND
31 GND 32 SIO_GPIO6
33 SIO_GPIO4 34 SIO_GPIO2
35 SIO_GPIO0 36 SIO_GPIO7
37 SIO_GPIO5 38 SIO_GPIO3
39 SIO_GPIO1 40 +V5_DUAL
The PPC-MB-610 motherboard features a number of
jumpersthatallowuserstocongurethesystemaccording
tospecicapplications.Thefunctionsofeachjumperand
connector are listed in the table below.
Connector and Headers
Connectors and Headers List
Label Function
CN2 Mic-In/Line-Out connector
LAN2_USB1 RJ45 + USB 3.1 stack connector
LAN1_USB1 RJ45 + USB 3.1 stack connector
VGA1 VGA display connector
DP1 DisplayPort connector
COM12 COM 1/2 connector
USB3 2 x USB 3.1 connector
ATX12v1 ATX 12V power supply connector
CN21 ATX power supply connector
CN5 Power button connector
CN6 COM 3/4/5 and GPIO connector
BAT1 Battery connector
SPI1 SPIBIOSashsocket
CN16 Touchscreen connector
CN17 LVDS panel connector
CN20 LVDS backlight inverter power connector
Sysfan1 ~ 2 System fan power connector
CPUFAN1 CPU fan power connector
SATA1 ~ 2 SATA signal connector
CN4 Power LED connector
CN9/CN12 2 x USB 2.0 pin header
PCIEX16_1 PCIe x16 slot connector
AMP1 Audioamplieroutputconnector
DIMMA1/
DIMMB1
DDR4 SODIMM socket
CPU1 CPU socket
M.2_2 M.2 E key
NGFF1 M.2 M key
Jumpers and Connectors
Jumpers and Connectors (Cont.)
