PPC-615W/618W/621W User Manual 2
1.1 Overview
The PPC-615W/618W/621W is a panel PC chassis developed for Mini-ITX mother-
boards. These chassis are equipped with a 15.6''/18.5''/21.5'' TFT LED panel. PPC-
615W/618W/621W supports a selection of Mini-iTX motherboards to satisfy diverse
customer requirements regarding price and functionality.
PPC-615W/618W/621W also features a true flat bezel to meet market demands for a
stylish design, as well as an additional reservation port and expansion slot to accom-
modate various applications. The PPC-615W/618W/621W series devices were
developed using two design concepts — optimization and compatibility.
Features:
PPC-615W/618W/621W true-flat PPC with project capacitive multi-touch
Supports certified Mini-ITX motherboards, up to 65 W TDP processor
Supports two PCI/PCIe expansion slots
Front-facing LED indicators for power status
Front panel is IP66 compliant
Optional VESA mount available upon request
1.2 Specifications
1.2.1 Specifications Comparison
Product PPC-615W PPC-618W PPC-621W
LCD 15.6'' 18.5'' 21.5''
Display Type
15.6'' TFT LCD
(with LED backlight)
18.5'' TFT LCD
(with LED backlight)
21.5'' TFT LCD
(with LED backlight)
Max. Resolution 1920 x 1080 1366 x 768 1920 x 1080
Pixel Pitch 0.18 x 0.18 mm 0.3 x 0.3 mm 0.25 x 0.25 mm
Viewing Angle
85 (left), 85 (right)
85 (top), 85 (bottom)
85 (left), 85 (right)
80 (top), 80 (bottom)
89 (left), 89 (right)
89 (top), 89 (bottom)
Brightness
450 cd/m
2
450 cd/m
2
250 cd/m
2
Contrast 800 1000 1000
Weight 6.1kg 7.6kg 8.4kg
Dimensions
419 x 269 x 108.2mm
(16.5'' x 10.6'' x 4.2'')
488 x 309 x 108.2mm
(19.2" x 12.1" x 4.2")
558 x 349.8 x 108.2mm
(21.9" x 13.7" x 4.26")
