27 PPC-415/417/419 EHL User Manual
Chapter 2 System Installation & Setup
Step D: Connect the ground pin of PPC system to the cabinet.
2.12 Optional Module Installation
The PPC-415/417/419 supports some optional modules: CFast module and COM
module (see Fig. 2.34).
Detailed installation instructions are provided below.
Figure 2.34
A. CFast Module Installation
1. Remove the screw on the side of the I/O cover (see Fig. 2.35).
Note! The protective earthing conductor wire should be green and yellow, with
a gauge of xx AWG (0.75mm²), and it must be connected to the build-
ing's grounding system. Prior to connecting the equipment to a power
outlet, please verify that the power source's voltage is correct. This can
be achieved by using a power cord that connects to a socket-outlet with
an earthing connection.
Note! Retain the I/O cover for future use when a module is not installed.
CFast Module COM Module
