PPC-415/417/419 EHL User Manual 2
1.1 Introduction
Advantech’s PPC-415/417/419 (15”/17”/19”) fanless panel PCs are powered by an
Intel® Atom™
x6425E processor that delivers high-performance computing and sup-
ports a wide operating temperature (-20 ~ 60
°C/-4 ~ 140 °F) and wide power input
range (9 ~ 32 V
DC
). The provision of multiple I/O interfaces, including four COM (of
which two are internal ports for an optional COM module), two USB 3.2, one isolated
RS-422/485, and dual Intel
®
Gigabit Ethernet, ensure easy integration of additional
peripherals and convenient deployment. A PCI/PCIe expansion slot is also provided
to support the addition of a fieldbus or proprietary card, increasing the application
potential for a wide range of industries.
1.2 Specifications
Table 1.1: Specifications
Product PPC-415-xX6 PPC-417-xX6 PPC-419-xX6
LCD Specification 15" LCD 17" LCD 19" LCD
Display Type
15" TFT LCD
(LED backlight)
17" TFT LCD
(LED backlight)
19" TFT LCD
(LED Backlight)
Max. Resolution 1024 x 768 1280 x 1024 1280 x 1024
Color 16.7M 16.7M 16.7M
Dot matrix 0.297 x 0.297 mm 0.264 x 0.264 mm 0.294x0.294 mm
Viewing Angle
80 (left), 80 (right),
70 (top), 70 (bottom)
80 (left), 80 (right),
60 (top), 80 (bottom)
85 (left), 85 (right),
80 (up), 80 (down)
Brightness
500 cd/m
2
350 cd/m
2
350 cd/m
2
Contrast 2500 800 1,000
Backlight Lifecycle 70, 000 hours 50, 000 hours 50, 000 hours
Touchscreen 5-wire analog resistive, projected capacitive (by request)
Weight 5.3 kg (11.6 Ib) 6.27 kg (13.9 Ib) 7.9kg (17.3Ib)
Dimensions
396.5 x 317.6 x 65.3(mm)
(15.6" x 12.5" x 2.57")
442.0 x 362.0 x 69.5 (mm)
(17.4" x 14.25" x 2.73")
458.2 x 384 x 67.3(mm)
(18" x 15" x 2.6")
Chipset Intel Atom Processor X6425E
Memory 1 x SODIMM DDR4 3200MHz (max.32GB)
Storage 1 x 2.5” SATA bay
1 x M.2 B key bay (size: 2242/2280 or 3042/3052 mm; Signal: SATA, PCIe x1,
USB 3.0)
Network (LAN) 2 x 10/100/1000/2500 Mbps Ethernet (Intel I226)
I/O Ports
5 x Serial ports: 2 x RS-232, 1 x RS-422/485 with 1K VDC isolation,2 x RS-
232 (on right side optional)
2 x USB 3.2, 3 x USB2.0 (2pcs default, 1pcs optional)
1 x Line-out, 1 x Mic-in, 2 x 1 W speaker (internal)
1 x HDMI 1.4
1 x DP 1.4
1 x GPIO (8 channels, TTL level) (optional)
1 x TPM2.0(internal)
Expansion Slots
1 x PCIe x 1 (default)
1 x PCI (optional)
1 x M.2 2230 E Key slot for wireless card
