PPC-3150SW/3180SW/324W-PN4 User Manual
2
1.1 Introduction
PPC-3150SW/3180SW/324W-PN4 is a high-value, ultra-slim panel PC equipped
with a 15.6"/18.5"/23.8" WXGA TFT LCD and low-power Intel® Pentium® N4200
quad-core (1.1 GHz) processor to provide high-performance computing in a compact
fanless system. For high durability and functionality, PPC-3150SW/3180SW/324W-
PN4 features an IP65-rated front panel, true-flat multi-touch projected capacitive
touchscreen, die cast aluminum alloy enclosure, two serial ports, four USB ports, and
two GbE LAN ports, making it suitable for diverse industrial applications.
1.2 Key Features
15.6"/18.5"/23.8" true-flat WXGA TFT LCD with projected capacitive touch con-
trol
Fanless design with low power consumption
1 x internal 2.5" SATA SSD and 1 x mSATA
Configurable RS-232/422/485 ports via BIOS
Automatic data flow control over RS-485
Wide range DC support (12 ~ 24 V
DC)
Supports dual displays
IP65-rated front panel
1.3 Front Panel
The PPC-3150SW/3180SW/324W-PN4 front panel is a true-flat color TFT LCD with
multi-touch projected capacitive touch control. Additionally, the front panel is IP65
rated for protection from dust and water ingress.
Figure 1.1 Front Panel
Note! Figure 1.1 shows the PPC-3150SW-PN4 model. The PPC-3150SW/
3180SW/324W-PN4 models all follow the same design.
Touchscreen
Aluminium bezel
LED indicator
for Power
