PPC-3100S/3120S/3150S/3210SW User Manual 2
1.1 Introduction
Advantech’s PPC-3100S/3120S/3150S/3210SW is a fanless ultra-slim panel PC
equipped with an industrial-grade TFT LCD and low-power Intel® Celeron® N2930,
1.86 GHz processor. PPC-3100S/3120S/3150S/3210SW provides high-performance
computing in a compact embedded system.
Designed for high durability, PPC-3100S/3120S/3150S/3210SW features a true-flat
5-wire resistive or projected capacitive touchscreen, IP65-rated front panel, and die
cast aluminum alloy enclosure. The system I/O includes two serial ports, two or three
USB ports, and dual GbE LAN to support diverse industrial applications. Moreover, to
enhance system monitoring and protection, an E-Eye LED display is included in the
rear cover for indicating the system status.
1.2 Key Features
Robust IP65-rated true-flat color TFT LCD
Ultra-thin fanless design with solid aluminum alloy enclosure
Intel
®
Celeron
®
N2930 quad-core, 1.83 GHz, processor
1 x 204-pin DDR3L SODIMM slot (supports up to 8 GB)
2 x Full-size mini PCIe card slots (one supports mSATA SSD)
1 x USB 3.0 port
Supports SATA 6Gb/s interface for 2.5” SATA storage
Supports E-Eye technology for enhanced system monitoring
Optional mini PCIe 802.11b/g/n wireless module
1.3 Front Panel
The PPC-3100S/3120S/3150S/3210SW front panel is a true-flat color TFT LCD
touchscreen with 5-wire resistive touch control. The front panel is IP65 rated for dust
and water tolerance (Figure 1.1).
Figure 1.1 PPC-3XX0S front panel
Note! The panel PC shown in Figure 1.1 is PPC-3100S. The PPC-3000S
model follows the same design.
Aluminium Frame
Touch Screen
LED Indicator
for Power
