POC-821 Series User Manual 2
1.1 Introduction
The POC-821 is a Point-of-Care terminal that utilizes a multimedia Intel® Core™ i7
or i5 processor designed for mobile computing. It is a PC-based system with a 23.8"
wide screen TFT LCD display, with HDMI and triple LAN connectivity. The device is
equipped with dual COM ports (RS232), 4 x USB 2.0 ports, and a 24-bit stereo audio
controller. Additionally, it can be equipped with an optional secondary 2.5" SSD stor-
age device.
For system integrators, the POC-821 offers a highly integrated multimedia system
that enables easy integration of a Point-of-Care Terminal into your applications. The
POC-821 is an ideal and secure point-of-care solution for patients and hospital prac-
titioners. It is specially designed to resist spills and water damage at the front panel,
while ensuring dust resistance with its protected LCD. With its reliability, and its ability
to meet your application's processing requirements, the POC-821 is a dependable
choice.
Intended use - The POC-82 is designed to serve as a user-friendly Point-of-Care
terminal, specifically for integration with hospital systems. The POC-821 is intended
for general-purpose computing within a hospital environment, servicing purposes
such as data collection information display. However, it should not be used as a life-
support system.
The latest version of this user manual is available for download from http://sup-
port.advantech.com.tw/support/
1.2 Specifications
Table 1.1: Specifications
Computing System
CPU
Intel® Core™ i7-9700E Processor (12M Cache, up to 4.40
GHz)
Intel® Core™ i5-9500E Processor (9M Cache, up to 4.20
GHz)*
Intel® Core™ i3-9100E Processor (6M Cache, up to 3.70
GHz)*
*depending on the project
Memory Supports up to 32GB DDR4 SODIMM
Graphics T1000 or RTX3000 MXM Graphics Module (optional)
Display
Display Size 21.5" wide TFT color LCD (16:9)
Type IPS
Max. Resolution 1920 x 1080 (H x V)
Max. Colors 16.7 M colors
Luminance 250 cd/m2
Backlight LED
Touch Type Projected Capacitive 10-points (clear glass).
Expansion Slots
M.2 2242 B-Key
(main storage)
1 (for M.2 SSD installation)
M.2 2230 E-Key
(Wi-Fi)
1 (for Wi-Fi module installation)
PCIe 1 x PCIe x16 (Slot is reserved for an MXM graphics module)
