POC-624 User Manual 2
1.1 Introduction
Advantech’s POC-624 series are point-of care (POC) terminals equipped with an
Intel® Core™ i7/i5/Celeron® processor, 23.8" widescreen TFT LCD display, and
water-resistant sealed I/O ports. Easily configured for a wide range of applications
and infrastructures, POC-624 terminals provide the ideal solution for diverse medical
computing operations. The front panel is IP65 rated for protection from water and
dust ingress, facilitating regular cleaning for enhanced hygiene and infection control.
Intended Use - The POC-624 series is designed to serve as general-purpose POC
terminals that can be integrated with existing hospital systems and used for data col-
lection/information displays. POC-624 terminals should not be used as life-support
systems.
The latest version of this user manual is available for download at the Advantech
website: http://support.advantech.com.tw/support/
1.2 Specifications
POC-624 Series Models
Model Name Model Differences
POC-624-11 DC-In model (with external Sinpro adapter)
POC-624-01 AC-In model (with internal FSP PSU)
System
Processor
Intel® Core™ i7-8665UE (8M cache, up to 4.40 GHz)
Intel® Core™ i5-8365UE (6M cache, up to 4.10 GHz)
Memory 8 GB DDR4 (supports up to 32GB DDR4 SODIMM)
Graphics Controller Intel® HD Graphics 620/610
Storage
Primary (Default) NVME SSD 256 GB (M.2 2280)
Secondary (Optional) 2.5” SATA SSD available
Display
Size 23.8”
Max. Resolution 1920 x 1080
Touch Type
10-point multi touch P-CAP (clear glass); optional AG/AR
upon request
Expansion Slot
Mini PCIe 1 (full size)
M.2 2230 1 (for Wi-Fi/Bluetooth module)
PCIe x4 1 (card length: 167.65 mm/6.6 in)
I/O
USB 3.2 Gen 2 (Type A) 2
USB 3.2 Gen 2 (Type C) 1 (with display function via USB type C alternative mode)
USB 2.0 Type A 2
HDMI 1
LAN 1.5 kV 2 (with isolation)
Mic-In/Headphone-Out 1/1
COM (RS-232) 1.5 kV 2
DC-In 18 V
DC (POC-624-11 model)
AC-In 100 ~ 240 V
AC, 47 ~ 63 Hz (POC-624-01 model)
Power Input DC/AC
DC model: 18V, max.
AC model: 100 ~ 240V, max. 150W
Certification EMC & Safety
Medical CE, FCC (IEC 60601-1-2, 4th edition)
EN 60601-1
UL 60601-1
Environmental
Operating Temperature 0 ~ 35 °C/32 ~ 95 °F
Storage Temperature 0 ~ 50 °C/32 ~ 122 °F
