Advantech POC-424 handleiding
Handleiding
Je bekijkt pagina 12 van 52
Contents
Chapter 1 General Information ............................1
1.1 Introduction ............................................................................................... 2
1.2 Specifications............................................................................................ 3
1.3
1.4
Dimensions ............................................................................................... 4
1.3.1 Optional Modules.......................................................................... 6
1.3.2 Cleaning and Disinfecting ............................................................. 7
Operating Principle.................................................................................... 7
1.5 Intended User Profile ................................................................................ 8
Chapter 2 System Setup.......................................9
2.1
2.2
A Quick Tour of the POC-424-14 SERIES ............... ................ ............ 10
2.1.1 Front View................................................................................... 10
Figure 2.1 Front View of the Point of Care Terminal ................. 10
2.1.2 Rear View ................................................................................... 11
Figure 2.2 Rear View of the Point of Care Terminal .................. 11
Figure 2.3 POC-424-14 Rear View of Multi I/O Ports .. . . . . ... 11
Installation Procedures............................................................................ 14
2.3
2.4
2.2.1 Connecting the Power Cord........................................................ 14
2.2.2 Figure 2.4 POC-424-14 Connecting the Power Cord ................ 14
2.2.3 Connecting the DCIN (Medical Type) ......................................... 14
2.2.4 Connecting the Ground Pin......................................................... 15
Figure 2.5 POC-424-14 Equipotential Terminal Pin.................. 15
Figure 2.6 Grounding Cable with Connector ............................ 15
Hot-Swappable Battery Module ... .......................................................... 16
Running the BIOS Setup Program .......................................................... 16
2.5 Installing System Software...................................................................... 23
2.6 Installing the Drivers................................................................................ 24
2.7 EMC Declaration ..................................................................................... 24
Chapter 3 Installation Process of Products and
Accessories
..
.
......
.
.....
.
.....
.
.....
.
.....
.
....
.
19
3.1 Install PC-BOX Pack into POC ............................................................... 20
Chapter 4 Operation and Safety ........................21
4.1 General Safety Guide.............................................................................. 22
4.2 Thermal................................................................................................... 22
4.3 Disconnect the Power ............................................................................. 22
4.4 Proper Handing....................................................................................... 23
Chapter 5 Install VESA Mounting ......................25
5.1 Install VESA Mounting ............................................................................ 26
Bekijk gratis de handleiding van Advantech POC-424, stel vragen en lees de antwoorden op veelvoorkomende problemen, of gebruik onze assistent om sneller informatie in de handleiding te vinden of uitleg te krijgen over specifieke functies.
Productinformatie
| Merk | Advantech |
| Model | POC-424 |
| Categorie | Niet gecategoriseerd |
| Taal | Nederlands |
| Grootte | 6840 MB |
Caratteristiche Prodotto
| Kleur van het product | Black, White |
| Bluetooth | Ja |
| Beeldschermdiagonaal | 23.8 " |
| Resolutie | 1920 x 1080 Pixels |
| Touchscreen | Ja |
