PCM-3718 Series User Manual 8
1.5 Daughterboards
We offer a wide variety of optional daughterboards to help you get the
most from your PCM-3718 card. You will need the PCLD-780 or PCLD-
880 Screw-terminal Board, or the PCLD-8115 Wiring Terminal Board to
make connections.
PCLD-789D Amplifier/Multiplexer Board
This analog input-signal conditioning board multiplexes 16 differential
inputs to one A/D input channel. A high-grade instrumentation amplifier
provides switch selectable gains of 1, 2, 10, 50, 100, 200 or 1000.
PCLD-788 Relay Multiplexer Board
This board multiplexes up to 16 differential inputs to one analog output
channel. It offers isolated break-before-make high voltage switching and
a CJC circuit for thermocouple measurement.
PCLD-786 SSR I/O Module Carrier Board
This board holds eight opto-isolated solid state relay modules and
provides an additional eight outputs to drive external applications.
PCLD-785B and PCLD-885 Relay Output Boards
These boards let you control relays through the PCM-3718’s 16-bit digi-
tal output channels. PCLD-785B provides 24 SPDT relays, while the
PCLD-885 provides 16 SPDT power relays.
PCLD-782B Isolated D/I Board
This board provides 24 opto-isolated digital inputs for connecting to
PCM-3718’s digital input channels.
