PCM-3618 User Manual 8
The user may change the interrupt status address via SW1.Please note that the
address decoder will occupy a continuous, 16-byte area related to the switch setting.
For example, if you set the switch to 210H, then the address 210H to 21FHwill all be
decoded. The various DIP switch settings (SW1) for the interrupt status register are
shown in the table.
Table 2.1: Interrupt Status Register SW1
Bit Function
0Port1
1Port2
2Port3
3Port4
4Port5
5Port6
6Port7
7Port8
A4 A5 A6 A7 A8 A9 Interrupt Register
ON ON ON ON ON ON 000H
OFF ON ON ON ON ON 010H
ON OFF ON ON ON ON 020H
OFF OFF ON ON ON ON 030H
ON ON OFF ON ON ON 040H
OFF ON OFF ON ON ON 050H
ON OFF OFF ON ON ON 060H
OFF OFF OFF ON ON ON 070H
ON ON ON OFF ON ON 080H
OFF ON ON OFF ON ON 090H
ON OFF ON OFF ON ON 0A0H
OFF OFF ON OFF ON ON 0B0H
ON ON OFF OFF ON ON 0C0H
OFF ON OFF OFF ON ON 0D0H
ON OFF OFF OFF ON ON 0E0H
OFF OFF OFF OFF ON ON 0F0H
ON ON ON ON OFF ON 110H
OFF ON ON ON OFF ON 110H
ON OFF ON ON OFF ON 120H
OFF OFF ON ON OFF ON 130H
ON ON OFF ON OFF ON 140H
OFF ON OFF ON OFF ON 150H
ON OFF OFF ON OFF ON 160H
OFF OFF OFF ON OFF ON 170H
ON ON ON OFF OFF ON 180H
