PCM-27D24DI User Manual 12
3.1 Overview
Maintaining signal connections is one of the most important factors in ensuring that
your application system is sending and receiving data correctly. A good signal con-
nection can avoid unnecessary and costly damage to your PC and other hardware
devices. This chapter provides useful information about how to connect input and
output signals to the PCM-27D24DI via the I/O connector.
3.2 Switch and Jumper Settings
Figure 3.1 Card Connector, Jumper and Switches
Table 3.1: Summary of Jumper Settings
Jumper Name Function Description
JP1
Load default while reset (default)
Keeps the last status after reset (enabled)
