PCIE-1824 User Manual 2
PCIE-1824 is a high-density multiple channel analog card for the PCIE bus, where
each analog output channel is equipped with a 16-bit DAC. It features optional volt-
ages, current output and a Board ID switch. PCIE-1824 is an ideal solution for indus-
trial applications where multiple analog output channels are required.
1.1 Features
32 high-density analog output channels
Flexible Output Range: ±10 V, 0 ~ 20 mA and 4 ~ 20 mA
Synchronized output function
Keep output values when hot system reset
High ESD protection (2,000 V
DC
)
Board ID switch
PCIE-1824 offers the following main features:
Keeps Output Values After System Reset
Users can independently set the 32 outputs to different ranges: ±10 V, 0 ~ 20 mA or 4
~ 20 mA, and all ranges are software selectable. When the system is hot reset
(power not shut down), the PCIE-1824 can either retain the last analog output values,
or return to its default configuration, depending on the jumper setting. This practical
function eliminates dangers caused by improper operation during unexpected system
resets.
BoardID Switch
The PCIE-1824 has a built-in DIP switch that helps define each card’s ID when multi-
ple PCIE-1824 cards have been installed on the same PC chassis. The BoardID set-
ting function is very useful when building a system with multiple PCIE-1824 cards.
With the correct BoardID settings, you can easily identify and access each card dur-
ing hardware configuration and software programming.
1.2 Applications
Process control
Programmable voltage source
Programmable current sink
Servo control
Multiple loop PID control
1.3 Installation Guide
Before you install your PCIE-1824 card, please make sure you have the following
necessary components:
PCIE-1824 card
PCIE-1824 User Manual
Driver software Advantech DAQNavi software (available for download from the
Advantech website
Note! For detailed specifications and operations of PCIE-1824, please refer to
Appendices A.
