23 PCIE-1824 User Manual
Appendix A Specifications
A.4 Current Output Accuracy
A.5 Dynamic Performance
A.6 Power Output
A.7 General
Gain error
Operating temperature within 5 °C of last auto-calibration tempe r a t u r e < ± 0 . 0 5 %
Over full operating temperature range <±0.15%
Offset error
Operating temperature within 5 °C of last auto-calibration tempe r a t u r e < ± 2 . 5 μ A
Over full operating temperature range <±10 μA
Slew rate 0.7 V/μs
Output noise 0.2 mVRMS
Channel to channel DC crosstalk
0.22 mV, measured channel at midscale, adjacent
channel at full scale
Settling time 100 μs
+5 V 200 mA max.
+12 V 100 mA max.
I/O Connector Type 62-pin D-sub
Dimensions
167 × 100 mm
2
(6.6 × 3.9 in.
2
)
Power Consumption
Typical 3.3 V @ 350 mA, 12 V @ 350 mA
Max. 3.3 V @ 370 mA, 12 V @ 1000 mA
Temperature
Operating 0~60°C (32~140°F)
Storage -40 ~ 70°C (-40 ~ 158°F)
Relative Humidity
Operating 10~90%RH non-condensing
Storage 5~95%RH non-condensing
Certifications CE/FCC certified
