3 PCIE-1816_1816H User Manual
Chapter 1 Introduction
Onboard Programmable Timer/Counter
The PCIE-1816/1816H features two 32-bit timer/counters to provide one shot output,
PWM output, periodic interrupt output, time-delay output, and the measurement of
frequency and pulse width.
BoardID Switch
The PCIE-1816/1816H has a built-in DIP switch that helps define each card’s ID
when multiple PCIE-1816/1816H cards have been installed on the same PC chassis.
The BoardID setting function is very useful when building a system with multiple
PCIE-1816/1816H cards. With the correct BoardID settings, you can easily identify
and access each card during hardware configuration and software programming.
1.2 Applications
Transducer and sensor measurements
Waveform acquisition and analysis
Process control and monitoring
Vibration and transient analysis
1.3 Installation Guide
Before you install your PCIE-1816/1816H card, please make sure you have the fol-
lowing necessary components:
PCIE-1816/1816H DA&C card
PCIE-1816/1816H User Manual
Driver software Advantech DAQNavi software (included in the companion DVD-
ROM)
Personal computer or workstation with a PCI Express interface (running Win-
dows 8 (desktop mode), 7 and XP)
Shielded Cable PCL-10168 or Shielded Cable with Noise Rejecting PCL-
10168H (optional)
Wiring Board ADAM-3968 (optional)
Other optional components are also available for enhanced operation:
DAQ Navi, LabView or other 3rd-party software
After you get the necessary components and maybe some of the accessories for
enhanced operation of your multifunction card, you can then begin the installation
procedure. Figure 1.1 on the next page provides a concise flow chart to give users a
broad picture of the software and hardware installation procedures:
Note! For detailed specifications and operation of the PCIE-1816/1816H,
please refer to Appendix A and B.
