PCIE-1730/1730H User Manual 16
A.1 Specifications
A.1.1 Isolated Digital Input
A.1.2 Isolated Digital Output
A.1.3 Non-Isolated Digital Input/Output
Input Channels 16
Input Voltage
Logic 0: 3 V max. (0 V
DC
min.)
Logic 1: 10 V min. (30 V
DC
max.)
Input Current
12 V
DC
@ 3.18 mA
24 V
DC
@ 6.71 mA
Interrupt-Capable
Channel
2 for PCIE-1730, 16 for PCIE-1730H
Digital Filter Channel 16 (for PCIE-1730H only)
Isolation Protection
2,500 V
DC
Overvoltage Protection
70 V
DC
ESD Protection
2,000 V
DC
Opto-Isolator Response 50 μs
Output Channels 16
Output Type Sink (NPN)
Isolation Protection
2,500 V
DC
Output Voltage
5 ~ 40 V
DC
*
Sink Current 500 mA max./channel
Opto-Isolator Response 50 μs
Note! When a inductance load is connected, the maximum output voltage will
be 24 V
DC.
Input Channels 16
Input Voltage
Low 0.8 V max.
High 2.0 V min.
Output Channels 16
Output Voltage
Low 0.5 V max. @ +24 mA (sink)
High 2.4 V min. @ -15mA (source)
Interrupt-Capable
Channel
2 for PCIE-1730, 16 for PCIE-1730H
Digital Filter Channel 16 (for PCIE-1730H only)
