AE_CON CoaXPress Frame Grabbers
CXP-2-12 BitFlow, Inc. Version C.1
AE_RUN_LEVEL R/W, AE_CON[3..0], Aon-CXP, Axion-CL, Claxon-CXP, Claxon-FXP, Cyton-CXP
This is the main control for starting/aborting acquisition. Writing this register changes
the current run level. Reading this register returns the current run level command (not
the current status). The abort run levels exit acquisition on a clean boundary. V exits
on a volume boundary, Z on a frame boundary, Y on a line boundary, X on a 128-byte
data boundary.
CLR_ACQ_
COUNT
RO, AE_CON[9], Aon-CXP, Axion-CL, Claxon-CXP, Claxon-FXP, Cyton-CXP
Write a 1 to this bitfield will reset to 0 the following registers V_ACQ_COUNT, Z_
ACQ_COUNT, Y_ACQ_COUNT and X_ACQ_COUNT.
AE_RUN_LEVEL Meaning
0 (0000b) System is idle
1 (0001b) Run - start running (i.e. acquiring)
2 (0010b) Abort V - stop at the end of the next volume
3 (0011b) Abort Z - stop at the end of the next frame
4 (0100b) Abort Y - stop at the end of the next line
5 (0101b) Abort X - stop at the end of the next 128-byte block
