The BitFlow CXP Models CoaXPress Frame Grabbers
CXP-1-14 BitFlow, Inc. Version C.1
1.6 The BitFlow CXP Models
There are two models of the Cyton-CXP. Table 1-1 illustrates the capabilities of each
model.
* CoaXPress over Fiber always uses a 10 Gb/S data rate. Cameras running CXP-3,
CXP-6 or other speed less than CXP-12 will actually a data over the fiber at 10 Gb/S.
For example, CXP-3 packets will be moving over the fiber at 10 Gb/S, there will be
more dead time between packets, so the average data rate will data will be the equiv-
alent of CXP-3 over copper.
** CoaXPress over Fiber uses 10 Gb/S fiber. However, it can still support CXP-12 data
rates. The reason is that CXP over copper uses 8B/10B encoding, and CXP over fiber
uses 64B/66B encoding, which more efficient.
Table 1-1 BitFlow CXP Models
Capability AON-
PC2-
CXP1
CLX-PC2-
CXP1
CLX-
PC3-
CXP2
CLX-
PC3-
CXP4
CLX-
PC3-
FXP4
CYT-
PC2-
CXP2
CYT-
PC2-
CXP4
Number of 3.125 Gb/S links 1 1 2 4 4* 2 4
Number of 6.25 Gb/S links 1 1 2 4 4* 2 4
Number of 12.5 Gb/S links 0 1 2 4 4** 0 0
Number of single link cameras 1 1 2 4 4 2 4
Number of dual link cameras 0 0 1 2 2 1 2
Number of quad link cameras 0 0 0 1 1 0 1
Number of Virtual Frame Grab-
bers
1 1 2 4 4 2 4
Number of independent trig-
ger inputs
1 1 2 4 4 2 4
Number of independent
encoder inputs
1 1 2 4 4 2 4
Number of PCI configurations
(devices)
1 1 2 4 4 2 4
Maximum DMA bandwidth 1.5 GB/S 1.75 GB/S 7.2 GB/S 7.2 GB/S 7.2 GB/S 3.5 GB/S 3.5 GB/S
