33 PCI-1780U User Manual
Appendix A Specifications
A.6 Power Consumption
Typical: +5V @ 200mA
Max: +5V @ 400mA
A.7 FPGA Code Update
FPGA code update function: Yes, through Advantech Navigator utility
A.8 General
Form factor: PCI Universal
Dimension: 175 x 100 x 18 mm (6.9 x 3.9 x 0.7 in.)
Weight: 98 g
I/O connector: Female 68-Pin SCSI (D-Type)
Operating temperature: 0°C to 60°C (32°F to 140°F)
Storage temperature: -20°C to 70°C (-4°F to 158°F)
Operating humidity: Up to 90% RH, non-condensing
Storage humidity: Up to 95% RH, non-condensing
Power supply output: +5 V (±5%) 200 mA max.
Table A.2: Signal Connection
Pin DI DO CLK GATE OUT FOUT +5V
Counter
Functions
Event
counting
V V
Frequency
measurement
V
Pulse width
measurement
V
One shot V V
Timer/pulse V V
Static Timer/
pulse
V
Pulse width
modulation
V V
