Je bekijkt pagina 8 van 58
PCI-1742U User Manual 2
Chapter 1 Introduction
1.1 Introduction
Thank you for buying the Advantech PCI-1742U PCI card. PCI-1742U is
a powerful high-resolution multifunction DAS card with 1MS/s sampling
rate and 16-bit resolution, fulfills the needs of most data acquisition appli-
cations. PCI-1742U provides 16 single-ended or 8 differential analog
input channels, two 16-bit D/A output channels, 16 digital input/output
channels, and one 10 MHz 16-bit counter channel.
The following sections will provide further information about features of
the multifunction cards, a quick installation guide, and some brief infor-
mation on software and accessories for the PCI-1742U card.
1.2 Features
The Advantech PCI-1742U provides users with the most requested mea-
surement and control functions as below:
• 16 S.E.or 8 Diff. analog input channels with 1K FIFO.
• 16-bit ADC with max. 1MS/s sampling rate
• Two 16-bit analog output channels
• 16DI/16DO TTL channels
• One 16-bit/ 10MHz counter
• Auto calibration function
• Universal PCI Bus (Support 3.3/5 V PCI Bus signal)
• Board ID switch
1.2.1 Auto-Calibration Function
The PCI-1742U provides an auto-calibration function with an calibration
utility. The built-in calibration circuitry of the PCI-1742U corrects gain
and offset errors in analog input channels, thereby eliminating the need
for external equipment and user adjustments.
