Chapter 3
– 24 –PCI-1721 User’s Manual
Advantech Co., Ltd.
www.advantech.com
3.3 Trigger Source Connections
Internal Pacer Trigger Connection
The PCI-1721 includes one 82C54 compatible programmable Timer/
Counter chip which provides three 16-bit counters connected to a 10
MHz clock, each designated specifically as Counter 0, Counter 1 and
Counter 2. Counter 0 is a counter which counts events from an input
channel or outputing pulse. Counter 1 and Counter 2 are cascaded to
create a 32-bit timer for pacer triggering. A low-to-high edge from the
Counter 2 output (PACER_OUT) will trigger an A/D conversion on
the PCI-1721. At the same time, you can also use this signal as a
synchronous signal for other applications.
External Trigger Source Connection
In addition to pacer triggering, the PCI-1721 also allows external
triggering for A/D conversions. When a +5 V source is connected to
EXT_GATE, the external trigger function is enabled. A low-to-high
edge coming from EXT_CLK will trigger an A/D conversion on the
PCI-1721. When DGND is connected to TRG_GATE, the external
trigger function is thereby disabled.
