PCI-1710U Series User Manual 30
Appendix A Specifications
A.1 Analog Input
Channels 16 single-ended or 8 differential or combination
Resolution 12-bit
FIFO Size 4k samples
PCI-1710U/UL
Max. Sampling
Rate
100 kS/s
PCI-1710HGU
Max. Sampling
Rate
Gain 0.5, 1 5, 10 50, 100 500, 1000
Speed 100 kS/s 35 kS/s 7 kS/s 770 S/s
Conversion Time 8 µs
Input Range and
Gain List for
PCI-1710U/UL
Gain 0.5 1 2 4 8
Unipolar N/A 0~10 0~5 0~2.5 0~1.25
Bipolar ±10 ±5 ±2.5 ±1.25 ±0.625
Input Range and
Gain List for
PCI-1710HGU
Gain 0.5 1 5 10 50 100 500 1000
Unipolar N/A 0~10 N/A 0~1 N/A 0~0.1 N/A 0~0.01
Bipolar ±10 ±5 ±1 ±0.5 ±0.1 ±0.05 ±0.01 ±0.005
PCI-1710U/UL
Drift
Gain 0.5 1 2 4 8
Zero 15 ppm/°C
Span 25 ppm/°C
PCI-1710U/UL
Small Signal BW
for PGA
Gain 0.5 1 2 4 8
Bandwidth 1MHz 3.3MHz 3.3MHz 2.8MHz 1.8MHz
PCI-1710HGU
Drift
Gain 0.5 1 5 10 50 100 500 1000
Zero 20 ppm/°C 50 ppm/°C
Span 40 ppm/°C 100 ppm/°C
PCI-1710HGU
Small Signal BW
for PGA
Gain 0.5 1 10 100 1000
Bandwidth 0.8MHz 3.2MHz 3MHz 0.65MHz 0.065MHz
Max. Input Volt-
age*
Common
mode Volt-
age(V)
-11 -8 -6 -
3.8~4
68 11
Max. Input
Voltage(V)
-2~-
11
-
5.6~1
0
-
7.4~
10
-
10~1
0
-
10~7.
5
-
10~5.7
5
-10~2
Input Impedance 300 MΩ / 5pF
Trigger Mode Software, on-board programmable pacer or external
