PCI-1285/1285E User Manual 34
External Drive Ext Master Src Indicates that axis is controlled by which
physical axis’s external signal.
Ext Sel Enable When Ext.drive is enabled, this property
enables driving axis selection by digital input
channel.
Ext Pulse Num The number of output driving pulses when an
active edge of input pulse is accept in Hand
Wheel mode.
Ext Preset Num The number of output driving pulses when an
active edge of input pulse is accept in JOG
mode.
Ext Pulse In Mode Sets the pulse input mode for external drive.
HLMT HLMT Enable Enables/Disables the hardware limit signal.
HLMT Logic Sets the active logic for hardware limit signal.
HLMT React Sets the reacting mode for hardware limit sig-
nal.
Home Home Ex Mode Sets the stopping modes for HomeEx().
Home Cross Distance Sets the home cross distance (Unit: Pulse)
for homing.
Home Ex Switch
Mode
Sets the stopping condition for HomeEx().
ORG Logic Sets the active logic for ORG signal.
EZ Logic Sets the active logic for EZ signal.
Home Reset Enable Enables/Disables reset logical counter after
homing for source axis.
ORG React Sets the reacting mode for ORG signal.
In Position Inp Enable Enables/Disables In-Position function for
source axis.
Inp Logic Sets the active logic for In-Position signal.
Latch Latch Enable Enables/Disables latch function for source
axis.
Latch Logic Sets the active logic for latch signal.
Pulse In Pulse In Mode Sets the encoder feedback pulse input mode
for source axis.
Pulse In Logic Sets the active logic for encoder feedback
pulse input signal.
Pulse In Source Sets the source for encoder feedback pulse
input signal.
Pulse In Max
Frequency
Sets the maximum frequency of encoder
pulse input signal.
Pulse Out Pulse Out Mode Sets the command pulse output mode for
source axis.
SD SD Enable Enables/Disables the SD signal for source
axis.
SD Logic Sets the active logic for SD signal.
SD React Sets the reacting mode for SD signal.
SD Latch Sets the latch control for SD signal.
Simulate Simulate Start Sets the simulate start source for this axis.
