PCI-1285/1285E User Manual 20
Naming Rules of API
The naming rules of API are as follows:
Acm_DevXXX: Represents this API will implement function for device, such as
device properties setting. Eg.Acm_DevSetProperty.
Acm_DaqXXX: Represents this API will implement the function of DI, DO, AI or
AO. Eg.Acm_DaqDiGetByte.
Acm_AxXXXX: Represents this API will implement function for axis, such as
single axis motion, homing. Eg. Acm_AxHome.
Acm_GpXXXX: Represents this API will implement function for multiple axes.
Such as interpolation motion. Eg. Acm_GpMoveLinearRel.
Naming Rules of Property
The properties have three types: feature, configuration and parameter.
Feature: Feature properties are related to the hardware features. The naming rules
are as follows:
FT_DevXXX: For device. Eg. FT_DevAxisCount.
FT_DaqXXX: For DI, DO, AI, and AO. Eg. FT_DaqDiMaxChan.
FT_AxXXX: For axis object. Eg. FT_Ax
FT_GpXXX: For group object.
Configuration: The values of configuration properties may change, but not fre-
quently.
CFG_DevXXX: For device. Eg. CFG_DevBoardID.
CFG_AxXXXX: For axis. Eg. CFG_AxMaxVel.
CFG_DaqXXX: For DI, DO, AI and AO. Eg. CFG_DaqDiMaxChan.
CFG_GpXXXX: For group object. Eg. CFG_GpAxisInGroup.
Parameter: The values of parameter properties may change frequently.
PAR_DevXXX: For device.
PAR_AxXXXX: For axis. Eg. PAR_AxVelLow.
PAR_DaqXXX: For DI, DO, AI and AO.
PAR_GpXXXX: For group. Eg. PAR_GpGroupID.
Info
In
formation
Cmp Compare
Inp In position
EZ Encode Z
EI Hardware Limit
Mel Negative Limit
Pel Positive Limit
Org Origin
Ext External
FT Feature Feature properties
CFG Configuration Configuration properties
PAR Parameter Parameter properties
Ipo Interpolation
Chan Channel
Table 4.1: Abbreviations and Their Meanings
