PCIE-1203 User Manual 8
1.3.3 Digital Input
1.3.4 Digital Output
1.3.5 Differential Output
1.3.6 General
Min. width for Hi / Lo pulse 350 ns
Channels LTC*2, MPG*1, DI*4
Type One terminal, opto-isolated
Input voltage
L(max)
3 V
dc
H(min)
10 V
dc
H(max)
30 V
dc
Max. input delay time
LTC, DI 0-1:350 ns
MPG, DI 2-3:100 us
Protection 2500V Isolation
Input resistance 8.4 kΩ
Channels CMP*2 & DO*2
Type One terminal, opto-isolated, sink type
Operation Voltage
min
3.3 V
dc
max
30 V
dc
Max. sink current 300 mA per channel
Max. output delay time 100 ns
Protection 2500V Isolation
Channels CMP+/-*1
Max frequency 1 MHz
Type Differential
Operation Voltage
Low
1.7V
dc
@ 100mA
High
4.6 V
dc
@ 0 mA
Protection 2500V Isolation
Bus Type Universal PCI Express x1-compliant
Power
+5V
DC
(from PCI-Bus)
Certification CE, FCC Class A
Connectors RJ45 x 2, DB26 x 1
Dimensions (L x H) 175 x 100 mm (6.9" x 3.9")
Power Consumption
5 V
DC
@ 0.5 A typical
Humidity 5 ~ 95% RH, non-condensing (IEC 60068-2-3)
Operating Temp. 0 ~ 60°C (32 ~ 140°F)
Storage Temp. -20 ~ 85°C (-4 ~ 185°F)
