PCE-5B18-0GA1 (PCE-7B19-0GA1) Startup Manual 1
Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 x 2-port USB Cable p/n: 1700002204
• PCE-5B18-0GA1 (PCE-7B19-0GA1)
• Startup Manual p/n: 20417B1900
• M4*6*0.7 Round Screws (15pcs) p/n: 1939000410
• 2 Year Quality Warranty Card p/n: 2190000902
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
PCE-5B18-0GA1 (PCE-7B19-0GA1) Backplane: 19
(18)-slot BP for 20-slot Chassis, 1 x PICMIG 1.3,
2 x (1) PCIe, 16 x 32-bit/64-bit PCI
Startup Manual
Standard Functions
• PICMIG 1.3 slots:
PCE-7B19-0G supports PCE-7xxx CPU boards
PCE-5B18-0G supports PCE-5xxx CPU boards
• PCIe slots:
PCE-7B19-0G supports two PCIe p1-x8 slots
PCE-5B18-0G supports one PCIe x16 slot
• 32-bit PCI slots:
Sixteen 32 bit/33 MHz, 64 bit/66MHz PCI slots
Bridge Chip: Diodes PI7C9X113SLFDE
• USB (2.0) ports:
Four Universal Serial Bus ports as pin headers
Mechanical and Environmental
• Dimensions: 327.66 x 417 mm
• Power supply voltage: +12 V, +5 V, -12 V, -5 V,
+3.3 V, +5 VSBY
• Power requirements: Refer to the CPU board, add-
on card & peripherals
• Operating temperature: 0 ~ 60°C
• Weight: 1.7 kg (weight of board)
Specications Packing List
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://support.advantech.com/
This manual is for the PCE-5B18-0GA1 (PCE-7B19-
0GA1) series.
Part No. 20417B1900
Printed in China
1st Edition
January 2025
