PCE-7132/5132/5032 User Manual 4
1.3.4 Graphics
Controller: Intel® HD Graphics embedded in the processor.
Display memory: Shared memory is subject to OS (install 2 GB or above mem-
ory for basic system configuration).
CRT: 2048 x 1152 @60 MHz.
DVI-D: 1920 x 1200 @60 Hz.
Display port: 4096 x 2304 @60 MHz, 24bpp.
PCI express x16/x8 slot on the backplane: An external graphic card can be
installed in the PCIe x16 / x8 slot for high 2D/3D graphics capability.
1.3.5 Ethernet LAN
Supports single/dual 10/100/1000 Mbps Ethernet port(s) via the dedicated PCI
Express p14-x1 bus which provides 500 MB/s data transmission rate.
Controller:
– LAN 1: Intel® I219LM (PCE-7132/5132); I219V (PCE-5032).
– LAN 2: Intel® i211AT (PCE-5132/5032); I210AT(PCE-7132).
1.3.6 Industrial Features
Watchdog timer: Can generate a system reset. The watchdog timer is pro-
grammable, with each unit equal to one second or one minute (255 levels).
1.3.7 Mechanical and Environmental Specifications
Operating temperature: 0 ~ 60 °C (32 ~ 140 °F, depending on CPU and ther-
mal solution).
Storage temperature: -40 ~ 85 °C (-40 ~ 185 °F).
Humidity: 20 ~ 95% non-condensing.
Power supply voltage: +3.3 V, +5 V, +12 V, +5 V
SB.
Power consumption: Processor: Intel W-1290E; Memory: 2DDR4 2666U 16
GB
Voltage +3.3 V +5 V +12 V
Current 1.09 A 1.30 A 0.5 A
Board size: 338.58 mm (L) x 126.39 mm (W) (13.3" x 4.98").
Board weight: 0.5 kg.
