PCE-7132/5132/5032 User Manual 2
1.1 Introduction
PCE-7132/5132/5032 is a PICMG 1.3 form-factor single host board which is
designed with Intel® W480E(PCE-7132), Q470E(PCE-5132), and H420E(PCE-
5032) PCH for industrial applications that need high computing power and diverse I/
O capabilities. PCE-7132/5132/5032 supports 14nm manufacturing technology,
LGA1200 socket Intel® Core™ i9/i7/i5/i3, Pentium® and Xeon™ processors that
integrate memory and graphic controllers, and support for DDR4 2933 SDRAM up to
64 GB. Within advanced computing technology, PCE-7132/5132/5032 is suitable for
processor hungry industrial applications.
PCE-7132/5132/5032 offers excellent graphics capability with its integrated Intel®
HD graphics core with a minimum 1 GB shared memory (requires a minimum 2 GB
system memory). With this, PCE-7132/5132/5032 provides strong 2D/3D graphics
processing power without an additional graphic card to save extra cost, power con-
sumption and thermal integration effort.
PCE-7132/5132/5032 features a multiple I/O interface: M.2 which can support M.2
(2280) type-M for PCIE devices (PCE-5032 board do not support M.2), SATA 3.0
ports with SW raid 0, 1, 5, 10 (PCE-5032 boards do not support RAID), integrated
USB 3.2 controllers, 2x RS-232 serial COM ports. Moreover, PCE-7132/5132/5032
can support Advantech PCE-5BXX and PCE-7BXX (PCE-7132/5132 only) series
backplanes offering various combinations of expansion such as PCI, PCI-X and PCIe
slots. With flexible I/O and graphic expansibility, PCE-7132/5132/5032 is an excel-
lent, cost effective graphic or I/O-oriented workstation class hardware platform. With
outstanding performance and exceptional features, PCE-7132/5132/5032 is the ideal
computing platform for advanced industrial applications.
1.2 Features & Benefits
Processor Support: Intel 10th generation family processors with the latest
14nm lithography.
Memory Capacity: Supports (ECC; W480E) DDR4 2933 U-DIMM 32 GB per
DIMM up to 64 GB memory capacity. DDR4 provides up to 50% increased per-
formance and bandwidth while saving up to 40% power.
Memory Technology: Supports up to 1024 M x 8 memory die.
Storage: Supports M.2 (2280) type-M SSD module for PCIE interfaces (PCE-
5032 boards do not support M.2), and SATA 3.1 ports with SW raid 0, 1, 5, 10
support (PCE-5032 boards do not support RAID).
High-Performance I/O Capability: Provides high transfer data performance
interface; USB 3.2 data transfer rate is 5 Gbps which is 10 times faster than
USB 2.0.
PCIe Architecture: Processor supports 16 link PCI Express generation 3.0 and
PCH support 4 links of PCI Express generation 3.0 to PICMG1.3 backplanes
(PCE-5032 only support generation 3.0 to PICMG1.3 backplanes).
SUSI API: Supports SUSI Access and Intelligent system module for remote
management.
