PCE-7131/5131/5031 User Manual 10
(JOBS1) is a 2-pin connector for setting enable/disable alarm while the on-board
security event acts.
1.9 System Memory
PCE-7131/5131/5031 has two 288-pin memory sockets for (ECC) DDR4 2400/2666
(Depends on CPU) memory modules with maximum capacity of 32GB. (Maximum
16GB for each DIMM)
PCE-7131 supports ECC and non-ECC DDR4 U-DIMM memory modules.
PCE-5131/5031 supports non-ECC DDR4 U-DIMM memory modules.
1.10 Memory Installation Procedures
To install DIMMs, first make sure the two handles of the DIMM socket are in the
“open” position. i.e. the handles lean outward. Slowly slide the DIMM module along
the plastic guides on both ends of the socket. Then press the DIMM module right
down into the socket, until you hear a click. This is when the two handles have auto-
matically locked the memory module into the correct position of the DIMM socket. To
remove the memory module, just push both handles outward, and the memory mod-
ule will be ejected by the mechanism in the socket.
1.11 Cache Memory
L3 memory cache size is subject to each Intel processor and please refer to the Intel
datasheet for detailed information.
Table 1.5: H/W Monitor Alarm (JOBS1)
Function Jumper Setting
Enabled
Disabled
1-2 closed (Default)
12
1-2 opened
12
Note! PCE-7131/5131/5031 do NOT support registered DIMMs (RDIMMs).
Note! Because PCE-7131/5131 supports Intel Active Management Technol-
ogy 11.0 (AMT12.0) which utilizes some memory space of channel 0, it's
suggested that the user should not leave channel 0 DIMM slots
(DIMMA1) empty, or it may cause some system abnormality.
