3 PCE-7131/5131/5031 User Manual
Chapter 1 Hardware Configuration
1.3 Specifications
1.3.1 System
CPU: LGA1151-socket Core i7/i5/i3, Pentium and Xeon E series processors
L2 cache: Please refer to CPU specification for detailed information
BIOS: AMI SPI BIOS (128 Mb SPI)
System chipset: Intel C246 (PCE-7131); Intel Q370 (PCE-5131); Intel H310
(PCE-5031)
SATA hard disk drive interface: Five (PCE-7131/5131) or four (PCE-5031)
SATA3 (600MB/s) ports are with blue connector. These interfaces can be
enabled/disabled in the BIOS.
M.2(2280) Type-M: Supports SATA3.0 with p11-x4 links device and PCIE interface
1.3.2 Memory
RAM:
– PCE-7131: Up to 32 GB in two 288-pin DIMM sockets. Supports dual-chan-
nel DDR4 2400/2666 SDRAM with or without ECC function.
– PCE-5131/5031: Up to 32 GB in two 288-pin DIMM sockets. Supports dual-
channel DDR4 2400/2666(Depends on CPU) SDRAM without ECC function.
1.3.3 Input/Output
PCIe bus: One PCIex16 or Two PCIex8 from CPU and One PCIe p11-x4 from PCH
PCI bus: Four PCI masters to the backplane, 32-bit, 33 MHz PCI 2.2 compliant.
Enhanced parallel port: This EPP/SPP/ECP port can be configured to LPT1,
LPT2, LPT3 or disabled. A standard DB-25 female connector is provided.
Serial ports: Two RS-232 serial ports
PS/2 keyboard and mouse connector:
One 6-pin mini-DIN connector is
located on the mounting bracket for easy connection to a PS/2 keyboard and
mouse via the Y-cable included in the package.
USB port: Supports 7 x USB 2.0 ports with transfer rates up to 480 Mbps. (5
ports are on the CPU card and 4 ports are on the backplane), and 6 USB
3.1(Gen1) ports with transfer rates of up to 5 Gbps, 1 USB 3.1 (Gen2) (for 7131/
5131 Only).
LPC: One LPC connector supports Advantech TPM LPC modules
GPIO: Supports 8-bit GPIO from super I/O for general purpose control applica-
tion
Note! 1. PCE-7131/5131/5031 does NOT support PATA (IDE) interface.
2. Only PCE-7131 supports Intel Xeon processors.
Note! A 32-bit OS may not fully detect 4 GB of RAM when 4 GB is installed.
Please select Intel ECC supported processor to enable ECC function.
