2 PCE-3032/PCE-4132 Startup Manual
The board has a number of jumpers that allow you to con-
gure your system to suit your application. The table below
lists the function of each of the jumpers and connectors.
Connectors
Label Function
LAN1
PCE-3032: Intel® I210AT
PCE-4132: Intel® I210AT
LAN2
PCE-3032: Intel® I210AT
PCE-4132: Intel® I210AT
VGA VGA connector
COM12 Box header for RS-232*2
FP1
HDD LED, power LED, SNMP SM_Bus,
reset, power on/o
JCASE1 Case open
CPUFAN1 CPU FAN connector (4-pin)
LANLED1 LAN1/2 LED connector
HDAUD1 HD audio extension module connector
USB3C1 USB 3.2 port 1
USB3C2 USB 3.2 port 2
USB3H1 USB 3.2 port 3, 4
USB2A1 USB 2.0 port 1
USB2C1 USB 2.0 port 2
USB2H1 USB 2.0 port 3, 4
USB2H2
USB 2.0 port 5, 6
SATA0 Serial ATA0 (SATA 3.0)
SATA1 Serial ATA1 (SATA 3.0)
SATA2 Serial ATA2 (SATA 3.0)
SATA3 Serial ATA3 (SATA 3.0, PCE-4132 only)
CPU CPU Socket
DIMMA1 Memory connector channel A
DIMMB1 Memory connector channel B
GPIO1 GPIO pin header
LPC2 Low pin count module expansion pin-header
PWR1 12 V, 5 V power connector
DP2
DVI/DP via optional cable
DP1
Display pin header to stack board (Display
type depends on optional stack board)
EXPCIE1 Mini PCIe pin header to stack board
Jumpers
Label Function
JCMOS1 CMOS clear
JWDT1+JOBS1
Hardware monitor alarm+watchdog
timer output selection
JME1 Enable ME
JCMOS1:ClearCMOS
ClosedPins Result
1-2 Keep CMOS (Default)
2-3 Clear CMOS
JOBS1+JWDT1:Hardwaremonitoralarm+watchdog
timeroutputselection
Function JumperSettings
2-3 Enable watchdog timer (Default)
4-5
Enable Hardware monitor alarm
(Default)
JME1:EnableME
ClosedPins Result
1-2
Enable ME
(Default)
2-3 Disable ME
1 2 3 4 5
1 2 3
JumpersandConnectors
JumpersandConnectors
(Cont.)
