PCE-3032/4132 User Manual 10
1.8.4 Watchdog Timer Output (JWDT1) and Hardware Monitor
Alarm (JOBS1)
PCE-3032/4132 contains a watchdog timer that will reset the CPU in the event the
CPU stops processing. This feature means PCE-3032/4132 will recover from a soft-
ware failure or an EMI problem. The JWDT1 jumper settings control the outcome of
what the computer will do in the event the watchdog timer is tripped.
PCE-3032/4132 also provide jumper: JOBS1 to enable or disable hardware monitor
alarm.
1.9 System Memory
PCE-3032/4132 has two 260-pin memory sockets for DDR4 2666/2933 MHz memory
modules with maximum capacity of 64 GB. (Maximum 32 GB for each DIMM)
Table 1.5: Watch Dog Timer (JWDT1) and Hardware Monitor Alarm
(JOBS1)
Function Jumper Setting
*Enable watch dog timer
*Enable hardware monitor alarm
* default setting
3
1 5
2-3 closed
3
1 5
4-5 closed
Note! Both PCE-3032 and PCE-4132 do NOT support registered DIMMs
(RDIMMs).
