3 PCE-3032/4132 User Manual
Chapter 1 Hardware Configuration
1.3 Specifications
1.3.1 System
CPU: LGA1200-socket Core i9/i7/i5/i3, Pentium and Xeon W-1200 series pro-
cessors.
L2 Cache: Please refer to CPU specification for detailed information.
BIOS: (PCE-3032) 128Mb SPI; (PCE-4132) 256Mb SPI.
System Chipset: Intel W480E (PCE-4132); Intel H420E (PCE-3032).
SATA hard disk drive interface: PCE-3032 supports three SATA 3.0 ports, and
PCE-4132 supports four SATA 3.0 ports.
1.3.2 Memory
RAM:
– PCE-4132: Up to 64 GB in two 260-pin SO-DIMM sockets. Supports dual-
channel DDR4 2666/2933 SDRAM WITH or WITHOUT ECC function.
– PCE-3032: Up to 64 GB in two 260-pin SO-DIMM sockets. Supports dual-
channel DDR4 2666/2933 SDRAM WITHOUT ECC function.
1.3.3 Input/Output
PCIe bus: One PCIe x16 or Two PCIe p13-x8 from CPU and One PCIe p13-x4 from
PCH.
Serial ports: Two RS-232 serial ports.
USB port: 6 x USB 2.0 (480Mbps) and 4 x USB 3.0
LPC: One LPC connector to support optional TPM (PCA-TPM-00B1E), COM-
232 (PCA-COM232-00A1E), COM-422/485 (PCA-COM485-00A1E) modules.
GPIO: Supports 8-bit GPIO from super I/O for general purpose control applica-
tion.
1.3.4 Graphics
Controller: Intel
®
HD Graphics embedded in the processor.
Display memory: Shared memory is subject to OS (install 2 GB or above mem-
ory for basic system configuration).
CRT: Up to 2048x1152 @ 60 Hz.
DVI-D: Up to 1920X1200 @60Hz.
Other display: Supports VGA + Display Port. Display type depends on optional
stack board.
PCI express x16/x8 slot on the backplane: An external graphic card can be
installed in the PCIe x16 /x8 slot for high 2D/3D graphics capability.
Note! PCE-3032/4132 do NOT support PATA(IDE) interface.
Only PCE-4132 supports Intel Xeon processors.
Note! Due to the inherent limitations of the PC architecture, the system may
not fully detect the exact capacity of RAM installed.
Please select Intel ECC supported processor to enable ECC function.
