3 PCA-6029 User Manual
Chapter 1 Hardware Configuration
1.3 Specifications
1.3.1 System
CPU: LGA1151-socket Core i7/i5/i3 and Pentium series processors.
L3 Cache: Please refer to CPU specification for detail information.
BIOS: AMI SPI BIOS (128 Mb SPI).
System Chipset: Intel H110.
SATA hard disk drive interface: Four SATA3 (600MB/s) with blue connectors.
These interfaces can be enabled/disabled in the BIOS.
1.3.2 Memory
RAM:
– PCA-6029: Up to 64 GB in two 240-pin DIMM sockets. Supports dual-chan-
nel DDR4 2133/2400 MHz SDRAM WITHOUT ECC function.
1.3.3 Input/Output
ISA bus: HISA (ISA high driver).
PCI bus: Four PCI masters to the backplane, 32-bit, 33 MHz PCI 2.2 compliant.
Serial ports: Two RS-232 serial ports.
PS/2 keyboard and mouse connector:
One 6-pin mini-DIN connectors is
located on the mounting bracket for easy connection to a PS/2 keyboard and
mouse via the Y-cable included in the package.
USB port: Supports 7 USB 2.0 ports with transfer rate up to 480 Mbps, and 3
USB 3.0 ports with transfer rate up to 5 Gbps.
LPC: One LPC connector to support Advantech TPM LPC modules.
GPIO: Supports 8-bit GPIO from super I/O for general purpose control applica-
tion.
1.3.4 Graphics
Controller: Intel® HD Graphics embedded in the processor.
Display memory: Shared memory is subject to OS (Please install 2 GB or
above memory for basic system configuration).
CRT: Up to 1920 x1080 resolution, 400 MHz RAMDAC.
DVI-D: One DVI-D pin header supports resolution up to 1920 x 1200 @ 60 Hz.
PCI slot on the backplane: An external graphic card can be installed on PCI
slots for stronger 2D/3D graphic capability.
1.3.5 Ethernet LAN
Supporting single/dual 10/100/1000 Mbps Ethernet port(s) via the dedicated
PCI Express p15-x1 bus which provides 500 MB/s data transmission rate.
Controller:
– LAN 1: Intel® i219-V.
– LAN 2: Intel® i211-AT.
Note! PCA-6029 does NOT support PATA (IDE) interface.
