MIO-5850 User Manual 8
2.1 Jumpers & Switches
The MIO-5850 has a number of jumpers that allow you to configure your system to
suit your application. The table below lists the functions of the various jumpers.
2.2 Connectors
Onboard connectors link the MIO-5850 to external devices such as hard disk drives,
a keyboard, or floppy drives. The table below lists the function of each of the connec-
tors.
Table 2.1: Jumpers & Switches
J1 Clear CMOS
J2 Auto Power on Setting
J4 LCD power
J5 LVDS VCON Setting
Table 2.2: Connectors
Label Function
CN1 M.2 E-key
CN2 RTC Battery
CN3 CAN Bus
CN4 SATA Power
CN6 Front Panel
CN7 SATA
CN8 Internal USB
CN9 Internal USB
CN10 COM1/COM2/RS232/RS422/RS485
CN11 COM3/COM4/RS232
CN12 I2C
CN13 SM Bus
CN14 FAN
CN16 Audio
CN17 GPIO_P0
CN18 GPIO_P1
CN19 mSATA
CN20 MINIPCI Express
CN22 Inverter Power output
CN23 RJ45
CN24 RJ45
CN25 48-bit LVDS
CN26 USB2.0+3.0
CN28 HDMI
CN29 Power Input
CN31 VGA
CN32 NAMO SIM
