MIO-5393 User Manual 10
2.1 Jumpers & Switches
The MIO-5393 has a number of jumpers that allow you to configure your system to
suit your application. The table below lists the functions of the various jumpers.
2.2 Connectors
Onboard connectors link the MIO-5393 to external devices such as hard disk drives,
a keyboard. The table below lists the function of each of the board's connectors.
Table 2.1: Jumpers & Switches
J1 Clean CMOS
J2 Auto Power on Setting
J3 COM1 Power Setting
J4 LCD Power
J5 LVDS VCON Setting
Table 2.2: Connectors
Label Function
CN1 Power Input
CN3 SO-DIMM 9.2mm
CN4 SO-DIMM 5.2mm
CN5 RTC Battery
CN7 CAN BUS
CN8 Front Panel
CN9 Audio
CN10 SM BUS
CN11 I2C
CN12 COM1
CN13 COM2
CN14 GPIO_P0
CN15 GPIO_P1
CN16 RJ45
CN17 Inverter Power output
CN18 48 bit LVDS
CN19 eDP
CN20 HDMI & DP
CN21 M.2 E-key
CN22 M.2 B-key
CN24 NAMO SIM
CN25 USB2.0+3.0_13H
CN26 USB2.0+3.0_13H
CN27 Internal USB
CN28 SATA Power
CN29 SATA_7V
CN30 SATA_7V
CN31 FAN
CN33 MIO
