MIO-5377 User Manual 2
1.1 Introduction
MIO-5377 is powered by 13th/12th Gen Intel
®
Core™ P/U series processors and
offers Advantech embedded software APIs, such as iManager 3.0, SUSI 4.0, and
DeviceOn, which were created by Advantech to monitor and control system opera-
tion effectively and remotely. Advantech has also validated MIO-5377 with the
embedded OS: Windows 10 LTSC and Ubuntu v22.04 LTS, ready for bundled ship-
ment.
MIO-5377 adopts the latest hybrid core processors to engender improvements in
CPU processing, graphics, security, and I/O flexibility. MIO-5377 was designed with
the latest USB4 for future expansion. With the MIOe-UMXM extension board, MIO-
5377 is expandable to accomodate an additional external embedded MXM graphics
module to provide extra GPU performance for AI applications.
1.2 Specifications
Platform Processor i7-1370PE i7-1370PRE i7-1270PE i7-1365UE i7-1365URE
Max. Frequency
(P-Core)
4.80 GHz 4.80 GHz 4.5 GHz 4.90 GHz 4.90 GHz
Base Frequency
(P-Core)
1.90 GHz 1.90 GHz 1.8 GHz 1.70 GHz 1.70 GHz
Core/Thread 6P+8E / 20T 6P+8E / 20T 4P+8E / 16T 2P+8E / 12T 2P+8E / 12T
Intel
®
Smart
Cache (L3)
24MB 24MB 18MB 12MB 12MB
CPU TDP 28W 28W 28W 15W 15W
Chipset On-package Intel 600 Series Chipset
BIOS AMI UEFI 256Mbit
Memory Technology DDR5-4800
Max. Capacity Up to 64GB
IBECC No Yes No No Yes
Channel/Socket Dual Channels / 2 sockets
Graphics Controller
Intel
®
Iris
®
Xe Graphics
Max. Frequency 1.40 GHz 1.40 GHz 1.35 GHz 1.30 GHz 1.30 GHz
Execution Units 96 96 96 96 96
3D/HW
Acceleration
DX12.1, OGL4.6, OCL3.0, HW Encode: H.265/HEVC, H.264, MPEG2, HW
Decode: H.265
Display I/F LCD 1 x LVDS: Dual Channel 18/24-bit, up to 1920 x 1200
HDMI/DP 1 x HDMI 2.0b, up to 4096 x 2160 x 24bpp@60Hz 1 x DP1.4, up to 4096 x 2304 x
36bpp@60Hz
Multiple Display 4 simultaneous displays via LVDS + HDMI + DP + USB Type-C Alt. Mode
Ethernet Controller LAN1: Intel i219; LAN2: Intel i226
Speed LAN1: GbE ; LAN2: 2.5GbE
TSN (LAN2 only) No Yes No No Yes
External I/O Ethernet 2 x RJ-45
HDMI/DP 1 x HDMI, 1 x DP
USB Type-C 1 x USB 3.2 Gen.2 x 1 10Gbps, support DisplayPort 1.4 Alt. Mode
USB Type-A 4 x USB 3.2 Gen.2 x 1 10Gbps
LED Power status, SATA R/W
Power DC-Jack Optional
Internal I/O SATA 1 x SATA Gen.3 6.0Gbps
USB4 1 USB4 with USB Type-C, Bandwidth min. 20Gbps, max. 40Gbps, with USB 3.2,
Display & PCIe
USB 2.0 2
COM Port 2 x RS-232/422/485, 2 x RS-232 (4-wire), max. 1Mbps
CAN Bus 2 x CAN 2.0
