3 MIO-5354 User Manual
Chapter 1 General Information
*Note: Support by Request
External I/O
Ethernet 2 x RJ-45
HDMI/DP 1 x HDMI + 1 x DP
USB 3.2 / USB
2.0
2 x USB 3.2 + 2 x USB 2.0
Internal I/O
SATA 1 x SATA Gen III 6.0Gbps
USB 3.0 2
Serial Bus
1 x I
2
C (*BOM option to SMBus by request)
COM Port 2 x RS-232/422/485, 2 x RS-232
CAN Bus 2 x CAN-FD, 2M/4M/8M bit/s or CAN 2.0, 1M bit/s
GPIO 8-bit general purpose input output I/O
Audio Realtek ALC888s, Line-in/Line-out/MIC
Inverter 5V @2A
Smart Fan 12V, 2A (4-wire)
Front Panel
Control
Power-on, Reset, Buzzer, SATA LED, Power LED, Case
Open
Board
Features
Watchdog Timer 65536 level, 0~65535 sec
TPM Discrete TPM2.0
iManager 3.0
SW API for Hardware Monitor, Smart Fan Control, Bright-
ness Control, I2C, GPIO, WDT
Expansion
M.2 E-Key 1 x E-Key 2230 (PCIe x1, USB 2.0)
M.2 B-Key
1 x B-Key 2280 (SATA or PCIe x1)
1 x B-Key 3052 (USB 3.0)
Power
Supply Voltage
Vin: DC 12V~24V ± 10%;
RTC Battery: Lithium 3V/200mAH, support w/o CMOS Bat-
tery
Connector
ATX 2pin 180D
(*BOM Option to ATX 2pin 90D or DC-IN Jack by request)
Power
Management
AT, ATX
Environment
Temperature
Operating: Standard: 0 ~ 60°C (32 ~ 140°F) with 0.7m/s
airflow;
Extend: -40 ~ 85°C (-40 ~ 185°F) with 0.7m/s airflow
Storage -40 ~ 85°C (-40 ~ 185°F)
Humidity Operating: 40°C @ 95% relative humidity, non-condensing
Vibration
Resistance
3.5 Grms
Certification EMC CE, FCC Class B, ESD 8KV/15KV Criteria A
Mechanical
Dimensions 146 x 102 mm (5.7" x 4")
Net Weight 145 g
Table 1.1: Specifications
