MIO-5272 User Manual 10
2.1 Jumpers & Switches
The MIO-5272 has a number of jumpers that allow you to configure your system to
suit your application. The table below lists the functions of the various jumpers.
2.2 Connectors
Onboard connectors link the MIO-5272 to external devices such as hard disk drives,
a keyboard, or floppy drives. The table below lists the function of each of the board's
connectors.
Table 2.1: Jumpers & Switches
J1 Auto Power On Setting
J2 LCD Power
SW2 Clear CMOS
Table 2.2: Connectors
Label Function
CN1 12V Power Input
CN2 DC JACK (Supported by request)
CN4 Battery
CN5 DDR3L SO-DIMM_1
CN6 DDR3L SO-DIMM_2
CN8 Power Switch
CN9 Reset
CN10 GPIO
CN11 SATA2
CN12 SATA1
CN13 SATA Power
CN14 Mini PCIE_1
CN15 mSATA or Mini PCIE_2
CN16 SIM
CN19 COM1/2 RS-232/422/485
CN21 Gigabit Ethernet 1 & 2
CN23 Audio
CN24 External USB3.0*2
CN25 External USB2.0*2
CN26 Internal USB
CN27 VGA
CN28 MIOe
CN29 SMBus
CN32 Inverter Power Output
CN33 48 bits LVDS Panel
CN34 HDMI
CN36 System FAN
