MIO-5154 User Manual 10
3.1 Jumpers & Switches
The MIO-5154 has a number of jumpers that allow you to configure your system to
suit your application. The table below lists the functions of the various jumpers.
3.2 Connectors
Onboard connectors link the MIO-5154 to external devices such as hard disk drives
and a keyboard. The table below lists the function of each of the board's connectors.
Table 3.1: Jumpers & Switches
JCMOS1 CMOS Clear Switch
VDD1 Panel Voltage Selection
RI_VDD1 COM RI# pin 5V/12V Selection
AT_ATX1 ATX/AT Mode Selection
Table 3.2: Connector and Header List
Description Location Name
DC Input Connector DCIN2
DC Input Connector (Adapter) DCIN1
Internal USB 3.1 Gen1 Connector USB1
COM Port Connector (RS232+RS422+RS485) COM1
COM Port Connector (RS232+RS422+RS485) COM2
COM Port Connector (RS232 only) COM3
COM Port Connector (RS232 only) COM4
COM Port Connector (RS232 only) COM5
COM Port Connector (RS232 only) COM6
Audio Connector AUDIO1
LVDS Connector LVDS1
SMB Bus Connector I2C_SMB1
FAN Connector FAN1
SATA Power Connector SATAP1
Inverter Connector BL1
GPIO Connector GPIO1
Power / LED / Case Open / Buzzer Connector FP1
M.2 B-Key (PCIe p20-x1 / USB 2.0) M2_B1
M.2 B-Key (SATA / PCIe x1) M2_B2
M.2 E-Key (PCIe p20-x1 / USB 2.0) M2_E1
RTC Battery Connector BAT1
Nano SIM Connector SIM1
