MIO-5154 User Manual 2
1.1 Introduction
The MIO-5154 is very similar to the 3.5" SBC form factor (compact series, 146 x 102
mm) and is powered by Intel® Core™ i3-N305 and Intel® Processor N-Series pro-
cessors. The MIO-5154 offers embedded iManager 3.0, SUSI 4.0, and WISE-Devi-
ceOn created by Advantech to monitor and control system operation effectively and
remotely.
The MIO-5154 supports single-channel DDR5-4800 up to 16GB, three independent
displays via LVDS, DP 1.4, HDMI 2.0 up to 4K@60Hz, Dual GbE, 6 x USB, 6 x UART,
and TPM 2.0.
1.2 Specifications
Table 1.1: Specifications
Platform
Processor i3-N305 N97 N50
Max. Frequency 3.80 GHz 3.60 GHz 3.40 GHz
Base Frequency TBU TBU TBU
Core/Thread 8/8 4/4 2/2
LLC 6MB 6MB 6MB
CPU TDP 15W 12W 6W
Chipset Intel® 300 Series Chipset (SoC Integrated)
BIOS AMI EFI 256 Mbit
Memory
Technology DDR5-4800
Max. Capacity Up to 16GB
Channel/Socket Single Channel / One Socket
ECC Support No No No
Graphics
Controller Intel® UHD Graphics
Max. Frequency 1.25 GHz 1.20 GHz 750 MHz
Execution Unit 32 24 16
3D/HW
Acceleration
DX12, OGL4.0, OCL1.2, HW Encode: HEVC/H265,
AVC/H264, VP9, HW Decode: HEVC/H265, AVC/
H264, VP9
Display I/F
LCD 1 x LVDS, Dual Channel 18-/24-bit, up to 1920 x 1080
HDMI/DP
1 x HDMI 2.0, up to 4096 x 2160 x 24bpp @48-60Hz
1 x DP1.4a, up to 4096 x 2304 x 36bpp @60Hz
Triple Display 3 simultaneous displays via LVDS + HDMI + DP
Ethernet
Controller LAN: Realtek RTL8111K
Speed 2 x GbE
External I/O
Ethernet 2 x RJ-45
VGA/HDMI/DP -/1/1
USB 3.2 / USB 2.0 2/2
