MIO-2375 User Manual 10
3.1 Jumpers and Switches
The MIO-2375 has a number of jumpers that allow you to configure your system to
suit your application. The table below lists the functions of the various jumpers.
3.2 Connectors
Onboard connectors link MIO-2375 to external devices such as hard disk drives or
keyboards. The table below lists the function of each of the board's connectors.
Table 3.1: Jumpers and Switches
SW1 Auto Power on Setting
VDD1 LCD Power
Table 3.2: Connectors
Label Function
CN1 Front Panel
CN2 GPIO
CN3 I2C
CN4 FAN
CN5 DC Power in
Battery1 RTC Battery
EDP1 eDP
BL1 Inverter Power Output
DP1 DP++
USB1 USB 2.0+3.2
USB3 Internal USB
M2_1 M.2 E-key
M2_2 M.2 B/M-key
SIM1 NANO SIM
LAN1 RJ45_2x1_W/XFMR&LED
SATA1 SATA_7V
Audio1 Audio
COM1 COM1
COM2 COM2
