Je bekijkt pagina 11 van 82
3 MIO-2375 User Manual
Chapter 1 General Information
*Note: Supported by request
Internal I/O
SATA 1 x SATA GenIII 6.0 Gbps
USB 2.0 2 x
Serial Bus I2C (support 400Kbit/s), *SMBus (optional)
COM Port 1 x RS-232/422/485 (support 1Mbps), 1 x RS-232 (115.2kbps)
GPIO 4-bit general purpose input output I/O
Audio Realtek ALC888s, Line-in/Line-out/MIC
Inverter 12V
Fan 4-wire smart fan
Front Panel Control Power-on, Reset, Buzzer, SATA LED, CaseOpen
Board Feature
Watchdog Timer 65536 level, 0~65535 sec
TPM TPM 2.0, Infineon SLB9670
iManager 3.0
SW API for Hardware Monitor, Smart Fan Control, Brightness
Control, I2C, GPIO, WDT
Expansion
M.2 E-Key 1 x E-Key 2230 (PCIe x1, USB2.0)
M.2 B-Key/M.2 M-
Key
1 x B-Key 3042/2242 (1 x SATA , 1 x USB 2.0) w/ Nano-SIM
Optional 1 x M-Key 2242 (PCIe p11-x2 NVMe)
Power
Supply Voltage Vin: DC 12V +/- 10%; RTC Battery: Lithium 3V/210mAH
Connector ATX 2pin 180D, optional DC-Jack
Power Management AT, ATX
Max. Consumption 23.388 W
Idle Consumption 9.029 W
Environment
Temperature
Operating: Standard: 0 ~ 60 °C (32 ~ 140 °F),
Extend: -40 ~ 85 °C (-40 ~ 185 °F)
Storage: -40 ~ 85 °C (-40 ~ 185 °F)
Humidity
Operating: 40 °C (104 °F) @ 95% relative humidity, non-condens-
ing
Storage: 60 °C (140 °F) @ 95% relative humidity, non-condensing
Vibration Resis-
tance
3.5 Grms
Software
OS Windows10, Linux 20.04, Yocto BSP
Software & API WISE-DeviceOn, Edge AI Suite, iManager 3.0
Certification EMC CE, FCC Class B
Mechanical
Dimensions 100 x 72 mm (3.93 x 2.83 in)
Net Weight 80g (.17 lb)
